Iemca Elite Zero Magazine Bar Feed

Ultra Thin, Ultra Smooth, Ultra Fast

The Elite Zero is the first bar feeder in the world machining ultra-thin bars
of 0.3 mm diameter. It is designed to meet the needs of those who are looking
for the accurate and smooth selection of extremely thin bars.

Technical Specs

ROUND BARS 0.3 - 2 mm (.012"- 1/16'')
HEXAGONAL BARS N.A.
SQUARE BARS N.A.
BAR LENGTH 450 - 2,560 mm (1'6" - 8'5")
REMNANT LENGTH 80 - 280 mm (3.15'' - 11.02'')
BAR WEIGHT N.A.
BAR CHANGEOVER TIME 30 sec
FEED RATE 750 mm/sec (1,770 in/min)
RETURN SPEED 1,200 mm/sec (2,830 in/min)
BAR FEEDER WEIGHT 650 kg (1,440 lbs)
COMPRESSED AIR 6 bar (87 psi)
INSTALLED POWER 1.5 kW
MP MAGAZINE AVAILABLE Walking Beam (max 37 bars)
F MAGAZINE AVAILABLE No
P MAGAZINE AVAILABLE No

Bar feeder includes: standard electrical and mechanical interface to the
lathe, walking beam magazine, synchronization device, remnant retraction
system and 1 guide channel set (1 Guide Channel, 1 Bar Pusher, 1 Rotating Tip,
1 Telescopic Nose and 1 Collet)

Pricing subject to change without notice

Accessories

Anti Vibration Device $1,990
Axial shifting device (Z) $1,990
Category III interface (Dual Channel Safety Circuit Protection) $1,490
Special adaptation kit (Required for some lathes) $1,990

Options

Touch screen 7" panel $490
Additional guide channel set $2,490
Spindle liner $350
Additional collets $80
Kit for additional status lights $80
Tool box $990
Wet upgrade for laser swiss application $5,000
Kit for low stock signaling light $790
Kit for 1 mm bar loading $690
Kit for Industry 4,0 $2,990

Installation

Installation in USA, Canada and Mexico $3,100
Installation price includes labor, travel expenses, on site operator training
at the time of installation, 12 month parts and labor warranty
