Star SV-32JII CNC Swiss Lathe, New in 2003

To the best of our knowledge all details listed below are deemed correct.
It is the buyer’s responsibility to confirm all details and we encourage an inspection of the machine(s) and accessories prior to purchase.

General Specifications:
Main Spindle:
Spindle Capacity: 1-1/4"
Spindle Speed: 100 - 7,000 RPM
Spindle Indexing: 15 Deg (C-Axis OP)
Headstock Stroke: 12 13/64"

Number of Tools:
OD Gang: 4
Turret: 8 Stations
Rotary: 3

Sub-Spindle
Spindle Speed: 100 - 7,000 RPM
Indexing: 15 Deg (OP), 1 Degree (OP)

Power:
Power Consumption: 7.0 KVA
Main Spindle Motor: 5.5 KW (Continuous)/7.5 (30 min)
Sub Spindle Motor: 2.2 KW (Continuous)/3.7 (15 min)

Dimensions(approx), L X W X H: 9' X 4' X 5.5'
Weight (approx): 7000 LBS
