Fusion Arc 180L Welding Cell, New in 2020

To the best of our knowledge all details listed below are deemed correct.
It is the buyer’s responsibility to confirm all details and we encourage an inspection of the machine(s) and accessories prior to purchase.

General Specifications:

Torch
Name: RT3500H (45deg)
Max. Operating Current: 350A (CO2 / MAG)
Rated Duty Cycle: 80% (CO2) / 60% (MAG)

Applicable Wire Diameter:
030”, .035”, .040”, 0.045” [STANDARD],
.052”, 1/16”(0.8mm,0.9mm,1.0mm,1.2mm
[STANDARD],1.4,1.6mm)

Cooling System: Air cooling
Shock Sensor: SSV (V6 / V6L), SSB (B4 / B4L)

Power Source
Name: RTW5000H (45deg)
Operating Current: 500A (CO2) / 400A (MAG)
Rated Duty Cycle: 70% (CO2) / 60% (MAG)

Cooling System: Water cooling

Robot
Model Number: FD-B6L
Structure: Vertical Articulated
Number of Axes: 6
Maximum Payload Capacity: 13.23 lbs.(6kg)
Positional Repeatability: +/-0.08 mm (1)
Driving Capacity: 4832W

Extended Cell Dimensions: 119.5” W x 213.5” L x 84” H
