HAAS VM-3 CNC VERTICAL MACHINING CENTER NEW: 2005 | MM 85559
$19,900.00 USD
ConditionUsed
1 available
PROBES
CHIP AUGER
REMOTE JOG HANDLE
SIDE MOUNT TOOL CHANGER
HIGH INTENSITY LIGHTING
TRAVELS:
X-AXIS: 40"
Y-AXIS: 26"
Z-AXIS: 25"
RAPID RATE X-AXIS: 710 IPM
RAPID RATE Y-AXIS: 710 IPM
RAPID RATE Z-AXIS: 710 IPM
TABLE SIZE: 54" X 25"
MAX TABLE LOAD: 4,000 LBS
SPINDLE MOTOR: 30 HP
SPINDLE SPEED: 12,000 RPM
SPINDLE TAPER: 40 CT
TOOL CHANGER: 24 ATC
MAX CUTTING: 500 IPM
MAX THRUST: 4,100 LBF
MAX TOOL DIAMETER: 2.5"
MAX TOOL DIAMETER: 5" MAX TOOL LENGTH 13"
MAX TOOL WEIGHT: 12 LB
TOOL-TO-TOOL: 2.8 S
CHIP-TO-CHIP: 3.6 S
COOLANT CAPACITY: 55 GAL
DIMENSIONS: 164" X 102" X 125"
WEIGHT: 15,300 LBS
