TSUGAMI BO205-II 7-AXIS CNC SWISS LATHE NEW: 2012 | AB 7611454

To the best of our knowledge all details listed below are deemed correct.
It is the buyer’s responsibility to confirm all details and we encourage an inspection of the machine(s) and accessories prior to purchase.

General Specifications:
Barstock Diameter (Main/Sub): 3/4" (20mm)
Machining Length: 8.26" / 1-3/4" (210mm w/ Guide Bushing / 45mm without)
Drilling Diameter (Main/Sub): 3/8" / 0.31"
Tapping Diameter (Main/Sub): M10(II) / M8(II)
Cross Drilling Diameter: 1/4" (Optional)
Cross Tapping Diameter: M5 x 0.8 (Optional)
Back Drilling Diameter: 1/4" (Optional)
Back Tapping Diameter: M5 (Optional)
Live Tool Speed: 5,000 RPM

Main/Sub Spindle Speed: 10,000 / 12,000 RPM
Tool Storage Capacity: 21
Tool Size: 0.47" x 0.47" x 3.3"
Rapid Traverse Rate: 1259 IPM (X1-Axis: 944 IPM)

Main/Sub Spindle Motors: 2.9 HP / 4.9 HP

Machine Dimensions: 65" x 44" x 66"
Machine Weight: 4,409 lbs
