Index G400 CNC Turning Center, New in 2002

All Specs Must Be Confirmed By the Buyer
General Specifications:

CNC Control yes
Type of CNC Control: Siemens 840D CNC Control
# Axis; 7
Max Swing Over Bed: 24.8"
Main Spindle Chuck Size: 17"
Max Turning Diameter: 16.54"
Max Turning Length: 80"
X-Axis (Cross Travel of Upper Turret): 12.6"
Z-Axis (Longitudinal Travel of Upper Turret): 80"
Y-Axis (Travel of Upper Turret): 8.27"
X2-Axis (Cross Travel of Lower Turret): 6.69"
Z2-Axis (Longitudinal Travel of Lower Turret): 80"
C-Axis (Indexing Positions of Main Spindle): 0.001°
C2-Axis (Indexing Positions of Sub Spindle): 0.001°
Main Spindle Max Bar Capacity: 4.02"
Main Spindle Horsepower: 71 HP
Max Main Spindle Speed: 3,000 RPM
Sub-Spindle Chuck Size: 16"
Sub-Spindle Max Bar Capacity: 4.02"
Sub-Spindle Horsepower: 67 HP
Max Sub-Spindle Speed: 3,000 RPM
X-Axis Upper Turret Cross Travel Rapid Traverse Rate: 787 IPM
Z-Axis Upper Turret Longitudinal Rapid Traverse Rate: 1575 IPM
X2-Axis Lower Turret Head Cross Travel Rapid Traverse Rate: 787 IPM
Z2-Axis Lower Turret Head Longitudinal Rapid Traverse Rate: 1575 IPM
Upper Turret Live Tooling Horsepower: 22.8 HP
Upper Turret Live Tooling Max Speed: 6,000 RPM
Upper Turret Positions: 12
Lower Turret Positions: 10
Lower Turret Live Tooling Horsepower: 15.2 HP
Lower Turret Live Tooling Max Speed: 6,000 RPM
Tailstock Rapid Traverse Rate: 1575 IPM
Approximate Machine Dimensions: 354" x 138"
Approximate Machine Height: 118"
Approximate Machine Weight: 46,300 LBS
